CMIF228 – CDMA-07

CMIF228 – CDMA-07
Datasheet

Product Specifications

General Parameters:
Frequency (MHz): 825 to 835, 870 to 880
Insertion Loss (dB Max): 1.5
Connectors: N-F
Designed for Systems: CDMA
Insertion Loss (dB Typ): 1.2
Passband Ripple (dB Max, p-p): 0.5
Return Loss (dB): 18
Stopband Attenuation (dB): 8 (+/- 7.5 MHz) 90 @ Channel
Operating Temperature: -30 to +55 ?
Storage Temperature: -40 to +85 ?
